全自动晾茬机是一种新型酿酒设备，具有速度快，效率高等特点。全自动晾茬机是由机架、风机、传送带、打料棍、下料装置、以及出料管组成的，该机将摊晾、加浆、加曲、搅拌、卸料等工艺一次性加工完成的，与传统工艺相比，大大的降低了劳动的强度，实现自动化生产。全自动晾茬机提高了冷却效果、同时降低了功耗，还了以前设备自积堵塞现象，是理想的冷散设备。
The fully automatic stubble drying machine is a new type of brewing equipment with fast speed and high efficiency. The fully automatic stubble drying machine is composed of a frame, a fan, a conveyor belt, a feeding rod, a feeding device, and a discharge pipe. The machine completes the processes of spreading, adding pulp, adding yeast, stirring, and unloading in one go. Compared with traditional processes, it greatly reduces labor intensity and realizes automated production. The fully automatic stubble drying machine improves the cooling effect, reduces power consumption, and solves the problem of self accumulation and blockage in the previous equipment, making it an ideal cooling and dispersing device.
每台全自动晾茬机都有接曲装置组成，接曲装置是全自动晾茬机比较重要的装置之一。接曲装置位于全自动晾茬机的底部，形成对下料口漏料的收集作用，从而节约物料，避免出现浪费的现象。下面介绍一下全自动晾茬机接曲装置的特征：
Each fully automatic stubble drying machine is composed of a bending device, which is one of the important devices of the fully automatic stubble drying machine. The bending device is located at the bottom of the fully automatic stubble drying machine, forming a collection function for material leakage at the discharge port, thereby saving materials and avoiding waste. The following is an introduction to the characteristics of the fully automatic stubble drying machine's bending device:
1、在全自动晾茬机的加曲料斗下料口正下方、处于全自动晾茬机底部的传动链条上方设置一接曲筐；
1. A curved basket is installed directly below the feeding port of the curved material hopper of the fully automatic stubble drying machine and above the transmission chain at the bottom of the fully automatic stubble drying machine;
2、接曲筐的两端分别固定在全自动晾茬机支架的横梁上；
2. The two ends of the connecting basket are respectively fixed on the crossbeam of the fully automatic stubble drying machine bracket;
3、接曲筐为一端抬起的折型护板；
3. The connecting basket is a folded protective plate that is lifted at one end;
4、且折型护板的抬起端设有调节螺栓用于调节接曲筐在横梁上的折型高度；
4. And the lifting end of the folded protective plate is equipped with an adjusting bolt to adjust the folded height of the connecting basket on the crossbeam;
5、以接曲筐形成对加曲料斗下料口中漏料的收集结构。
5. A collection structure is formed by connecting the curved basket to collect the leaked material in the discharge port of the adding curved hopper.
6、本实用新型能有效地对漏料进行收集和二次利用，从而节约物料。
6. The utility model can effectively collect and reuse leaked materials, thereby saving materials.
