全自动凉茬机的使用提高了冷却效果、降低了功耗，了现有设备自积堵塞现象，并实现了酒茬和酒曲的自动混合，那么您知道全自动凉茬机电机使用前的检查方法是怎样吗？

The use of automatic stubble cooler improves the cooling effect, reduces power consumption, solves the self accumulation and blockage of existing equipment, and realizes the automatic mixing of wine stubble and distiller's yeast. Do you know the inspection method of automatic stubble cooler motor before use?

全自动凉茬机主要由机架、风机、传送带和依次连接于传送带上的搅笼、打料棍、翻料棍、下料装置、出料管组成，使用时，酒茬在传送带上通过，在打碎和搅拌的同时风机工作，迅速降温，冷却后的酒茬在下料装置中与酒曲自动混合均匀。

The full-automatic stubble cooler is mainly composed of a frame, a fan, a conveyor belt and a stirring cage, a beating stick, a turning stick, a blanking device and a discharge pipe connected to the conveyor belt in turn. When in use, the stubble passes through the conveyor belt. While crushing and mixing, the fan works to quickly cool down. The cooled stubble is automatically mixed with koji in the blanking device.

在启动全自动凉茬机机之前，我们应当先检查机器的电机是否正常，再去启动设备。在检查时，应同时使用吹风机对电机内的灰尘等污垢杂物清理干净，还要测量接线是否合格，如果发现电机出现机械损伤或者火花灼痕应当立即进行必要的处理工作。

Before starting the automatic stubble cooler, we should first check whether the motor of the machine is normal, and then start the equipment. During the inspection, the blower should be used to clean the dust and other dirt in the motor at the same time, and measure whether the wiring is qualified. If the motor is found to have mechanical damage or spark burns, necessary treatment should be carried out immediately.

1、用压缩空气或手动吹风机吹净电动机内部灰尘、电刷粉末等，污垢杂物。

1. Blow the dust and brush powder inside the motor with compressed air or manual blower to remove dirt and sundries.

2、拆除与电动机连接的一切接线，用绝缘电阻表测量绕组对机座的绝缘电阻。若小于0．5MΩ时，应进行烘干处理，测量合格后再将拆除的接线恢复。

2. Remove all wiring connected to the motor, and measure the insulation resistance of the winding to the base with an insulation resistance meter. If it is less than 0.5m Ω, it should be dried, and the removed wiring should be restored after the measurement is qualified.

3、检查凉全自动凉茬机换向器的表面是否光洁，如发现有机械损伤或火花灼痕应进行必要的处理。

3. Check whether the surface of the commutator of the full-automatic stubble cooler is smooth and clean. If mechanical damage or spark burn marks are found, necessary treatment should be carried out.

4、检查电刷是否严重损坏，刷架的压力是否适当，刷架的位置是否位于标记的位置。

4. Check whether the brush is seriously damaged, whether the pressure of the brush holder is appropriate, and whether the position of the brush holder is at the marked position.

5、根据全自动凉茬机电动机铭牌检查直流电动机各绕组之间的接线方式是否正确，电动机额定电压与电源电压是否相符，电动机的起动设备是否符合要求，是否完好无损。

5. According to the nameplate of the motor of the automatic stubble cooler, check whether the wiring mode between the windings of the DC motor is correct, whether the rated voltage of the motor is consistent with the power supply voltage, and whether the starting equipment of the motor meets the requirements and is intact.

以上便是对全自动凉茬机电机使用前的检查方法的简单介绍，了解更多设备内容就来关注我们网站http://www.qfrtrq.com吧！

The above is a brief introduction to the inspection methods of the automatic stubble cooler motor before use. For more information about the equipment, please pay attention to our website http://www.qfrtrq.com Come on!
