全自动凉茬机的结构组成及机架介绍

发布于:2022-07-19 19:11:59  来源:http://www.qfrtrq.com

全自动晾茬机是一种新型酿酒设备,具有速度快,效率高等特点。可自动加水、下曲、出料、搅拌均匀、散冷效果及其理想。下面来介绍下全自动凉茬机的结构组成及机架相关内容。
Automatic stubble drying machine is a new type of brewing equipment, which has the characteristics of high speed and high efficiency. It can automatically add water, bend, discharge, stir evenly, and have ideal cooling effect. Next, we will introduce the structure of the automatic stubble cooler and the related contents of the rack.
全自动凉茬机的结构组成
Structure of automatic stubble cooler
1.主要由机架、风机、传送带和依次连接于传送带上的搅笼、打料棍、翻料棍、下料装置、出料管组成.
1. It is mainly composed of a frame, a fan, a conveyor belt and a stirring cage, a beating stick, a turning stick, a blanking device and a discharge pipe connected to the conveyor belt in turn
2.风机固定在传送带侧端的机架上并至少设置为三台,所述的下料装置由下料斗和固接于下料斗下部的下料辊组成,所述的机架上设有高于传送带输送线两边的挡板。
2. The fan is fixed on the frame at the side end of the conveyor belt and is set with at least three sets. The blanking device is composed of a blanking hopper and a blanking roller fixed at the lower part of the hopper. The frame is provided with baffles higher than both sides of the conveyor line of the conveyor belt.
3.使用时,酒茬在传送带上通过,在打碎和搅拌的同时风机工作,迅速降温,冷却后的酒茬在下料装置中与酒曲自动混合均匀。
3. When in use, the wine stubble passes through the conveyor belt. While crushing and mixing, the fan works to quickly cool down. The cooled wine stubble is automatically mixed with koji in the blanking device.
4.全自动打茬机提升了冷却效果、降低了功耗,解决了现有设备自积堵塞现象,并实现了酒茬和酒曲的自动混合。
4. The full-automatic stubble cutting machine improves the cooling effect, reduces power consumption, solves the self accumulation blockage of existing equipment, and realizes the automatic mixing of wine stubble and distiller's yeast.
全自动凉茬机
全自动晾茬机机架
Relevant introduction of the frame of automatic stubble drying machine
全自动晾茬机的特征是:由机架、风机、传送带和依次连接于传送带上的搅笼、打料辊、翻料辊、下料装置、出料管组成,风机固定在传送带侧端的机架上并至少设置为三台,下料装置由下料斗和固接于下料斗下部的下料辊组成,机架上设有高于传送带输送线两边的挡板。
The full-automatic stubble drying machine is characterized by: it is composed of a frame, a fan, a conveyor belt and a stirring cage, a beating roller, a turnover roller, a blanking device and a discharge pipe connected to the conveyor belt in turn. The fan is fixed on the frame at the side end of the conveyor belt and is set with at least three sets. The blanking device is composed of a lower hopper and a blanking roller fixed at the lower part of the lower hopper. The frame is equipped with baffles higher than both sides of the conveyor line of the conveyor belt.
全自动晾茬机包括机架,机架的上料端与加料结构连接、出料端与出料结构连接,上料端设有一带轮,出料端设有二带轮,一带轮与二带轮通过输送带连接,二带轮通过减速机与驱动电机连接,驱动电机与机架连接,二带轮位置高于一带轮位置。
The full-automatic stubble drying machine includes a frame. The feeding end of the frame is connected with the feeding structure, and the discharging end is connected with the discharging structure. The feeding end is equipped with a belt wheel, and the discharging end is equipped with two belt wheels. The belt wheel is connected with the two belt wheels through the conveyor belt, and the two belt wheels are connected with the drive motor through the reducer. The drive motor is connected with the frame, and the position of the two belt wheels is higher than the position of the belt wheel.
每台晾茬机都有接曲装置组成,接曲装置是晾茬机比较重要的装置之一。接曲装置位于晾茬机的底部,形成对下料口漏料的收集作用,从而节约物料,避免出现浪费的现象。更多相关内容就来网站http://www.qfrtrq.com咨询了解吧!
Each stubble airing machine is composed of a bending device, which is one of the more important devices of stubble airing machine. The bending device is located at the bottom of the stubble drying machine to collect the leaked materials at the blanking port, so as to save materials and avoid waste. Come to the website for more relevant content http://www.qfrtrq.com Consult and understand!
