全自动凉茬机是一种新型的酿造设备，具有速度快、效率高的特点。可自动加水、弯管、卸料、搅拌均匀，冷却效果理想。弯曲装置是冷茬机中比较重要的装置之一。弯管装置位于冷茬机底部，对出料口漏出的物料形成收集作用，从而节省材料，避免浪费。

Automatic stubble cooler is a new type of brewing equipment, which has the characteristics of high speed and high efficiency. It can automatically add water, bend pipes, unload materials and mix evenly, with ideal cooling effect. Bending device is one of the most important devices in stubble cooler. The elbow device is located at the bottom of the stubble cooler to collect the materials leaked from the discharge port, so as to save materials and avoid waste.

凉茬机本身就有很好的优势

The stubble cooler itself has good advantages

冷茬机是在将残茬冷却搅拌后，加入酒曲进行混合的设备。工作时间短，非常节省资源，自动上下料，减轻工人劳动强度，杜绝浪费粮食的现象。与颗粒接触的部分均采用不锈钢制造。此外，机器在使用时，输送、搅拌、下降均采用变频调速。

The stubble cooler is a device that adds distiller's yeast for mixing after cooling and stirring the stubble. The working time is short, which can save resources. It can automatically load and unload materials, reduce the labor intensity of workers, and eliminate the phenomenon of wasting food. The parts in contact with particles are made of high-quality stainless steel. In addition, when the machine is in use, frequency conversion speed regulation is adopted for conveying, mixing and lowering.

使用时，酒茬在传送带上通过，风机边粉碎搅拌边工作，温度迅速降温，冷却后的酒茬与进料装置中的酒曲自动混合。本实用新型的全自动凉茬机提高了冷却效果，降低了电耗，了现有设备的自积堵现象，实现了残茬和酒曲的自动混合。

When in use, the wine stubble passes through the conveyor belt, the fan works while crushing and mixing, the temperature drops rapidly, and the cooled wine stubble is automatically mixed with the starter in the feeding device. The full-automatic stubble cooler of the utility model improves the cooling effect, reduces the power consumption, solves the self accumulation and blocking phenomenon of the existing equipment, and realizes the automatic mixing of stubble and koji.

在启动自动冷茬机前，要检查机器的电机是否正常，然后再启动设备。检查时应同时用吹风机吹扫电机内的灰尘等脏物，并测量接线是否合格。如果发现电机有机械损坏或火花，应立即进行必要的处理。

Before starting the automatic stubble cooler, first check whether the motor of the machine is normal, and then start the equipment. During the inspection, the blower shall be used to purge the dust and other dirt in the motor and measure whether the wiring is qualified. If mechanical damage or sparks are found in the motor, necessary treatment shall be carried out immediately.

凉茬机是如何达到节材目的的：

How does the stubble cooler achieve the purpose of material saving:

1、在冷茬机料斗进料口正下方、冷茬机底部传动链上方设置弧形筐；

1. An arc-shaped basket is arranged directly below the hopper feed port of the stubble cooler and above the transmission chain at the bottom of the stubble cooler;

2、连接篮的两端分别固定在冷茬机支架的横梁上；

2. Both ends of the connecting basket are respectively fixed on the cross beam of the stubble cooler support;

3、弯篮为一端抬起的折叠护板；

3. The bent basket is a folding guard board raised at one end;

4、折叠护板的凸起端设有调节螺栓，用于调节弯篮在横梁上的折叠高度；

4. The convex end of the folding guard plate is provided with an adjusting bolt for adjusting the folding height of the bending basket on the beam;

5、弧形料斗出料口漏出物料的收集结构由弧形转篮构成。

5. The collecting structure of materials leaked from the discharge port of the arc hopper is composed of an arc-shaped rotating basket.

6、本实用新型可有效收集和再利用泄漏物，从而节省材料。

6. The utility model can effectively collect and reuse the leakage, thereby saving materials.
